Lub Clock Caij Nplooj Ntoos Hlav 25560-BH00 yog ib feem tseem ceeb ntawm koj lub tsheb kauj vab - ntsiag to ua nws txoj haujlwm txhua zaus koj tig lub log. Nws ua kom cov hluav taws xob sib txuas nyob nruab nrab ntawm lub kauj kauj thiab txhua yam ntawm lub log: lub airbag, horn, cruise control, thiab lwm yam nyees khawm. Tsis muaj teeb meem pes tsawg zaus koj tig lub log, nws xa cov paib huv si, ruaj khov yam tsis muaj kev cuam tshuam.
Ua kom haum OEM specs, chav tsev no haum ncaj qha rau hauv xaiv Honda, Nissan thiab Acura qauv uas tsis muaj kev twv ua haujlwm lossis ntxiv qhov xav tau. Cov ntaub ntawv tawv thiab cov qauv tsim ntse txhais tau tias nws siv tau ntev txog xyoo ntawm kev siv, cua sov, thiab kev vibration- yog li koj lub tshuab kev nyab xeeb tau npaj txhij, thiab koj cov kev tswj hwm ua haujlwm zoo li lawv yuav tsum tau ua.
Ntsiab nta
Exact Fit rau Honda / Acura Models
Engineered rau OEM specifications rau kev hloov ncaj qha. Tsis muaj adapters, rewiring, los yog kwv yees ua haujlwm xav tau -tsuas yog ntsia liaj qhov rooj rau hauv thiab rov txuas lub hlua.
01
Txhim khu kev ntseeg tau los ntawm txhua qhov tig
Ua nrog lub siab - voj voog hloov tau yooj yim ca cable uas ua haujlwm ntau txhiab kauj ruam kev sib hloov yam tsis muaj teeb liab poob. Khaws koj lub hnab airbag, horn, cruise control, thiab paddle shifters ua haujlwm zoo.
02
Durable, Thaum tshav kub kub-Resistant Vaj tse
Ua los ntawm cov nplaim hluav taws-cov khoom siv tiv thaiv PA66 yas, ruaj khov ntawm -40℃rau +85℃. Tin-plated terminals tiv thaiv corrosion, txawm nyob rau hauv ib puag ncig ntub los yog qab ntsev.
03
Tiv thaiv Plua plav thiab noo noo
Kev tsim qauv kaw pab thaiv lub cav bay cov kab mob. Txawm hais tias tsis muaj dej tsis txaus, nws tau tsim los tswj cov xwm txheej hauv qab - kev khiav ceev yam tsis muaj kev cuam tshuam sab hauv
kev ua.
04
Kev kuaj xyuas lub Hoobkas nruj
Ua raws li ISO / TS 16949 tus qauv. Txhua chav tsev raug sim rau kev sib hloov smoothness, hluav taws xob txuas ntxiv, thiab thermal endurance- yog li koj tau txais kev ua haujlwm zoo ib yam ntawm lub thawv.
05
Technical Specifications
|
Yam khoom |
Specification |
|
Qauv nab npawb |
25560-BH00 ib |
|
Qhov ntev |
Kwv yees . 165 × 65 × 55 mm (vim me ntsis los ntawm pawg) |
|
Hloov Cov Qauv |
25560-BH00A, 25560-BH01, 77900-TG5-A01 (OEM cross) |
|
Siv tau Systems |
Tsav tsheb airbag, horn, steering wheel audio/phone/cruise controls |
|
Lub kaum sab xis tig |
± 540℃(3 tag nrho lem) |
|
Kev khiav hauj lwm voltage |
12V DC lub zog |
|
Ua haujlwm kub |
-40℃~ +85 degree |
|
Khoom siv tsev |
Nplaim taws-Retardant reinforced PA66 |
Kev sib xyaw ua ke
1. Core Assembly:Dawb kauv reel nyob rau hauv ib tug dub engineering yas vaj tse, nrog nruj nreem kaw FPC cables enables nruam kev sib hloov.
2.Electrical Connectors:
(1) Sab Tsheb:Feem ntau 8-pin thiab 10-pin dawb connectors.
(2) Steering Log Sab:Yellow airbag plug (SRS) + pins dawb ntxiv rau cov nyees khawm ntau.
3. Mounting Base:Integrated positioning clips and screw bosses ensure a tight, rattle -free fit on Honda/Acura steering columns.
4.Centering Mechanism:Internal nres-thiab- rov qab feature tiv thaiv dhau- kev sib hloov thiab tiv thaiv lub cable thaum nruab.
Cov qauv tsheb sib xws
Honda:Accord (2013–2017), CR-V (2012–2016), Civic (2016–2021)
Nissan: Murano (2015-2020), Pathfinder R52
Acura:RDX (2013-2018), ILX (2013-2015)
Installation thiab siv sau ntawv
1.Ib txwm nyob nruab nrab ntawm lub kauj tsheb ua ntej kev txhim kho. Manually tig lub moos caij nplooj ntoos hlav lub hub sab hauv mus rau nws txoj hauj lwm nruab nrab (feem ntau cim) kom tsis txhob muaj cable khi.
2.Tsis txhob yuam cov connectors -lawv yuav tsum nias kom du. Kev quab yuam tuaj yeem ua rau cov pins tsis muaj zog.
3.Tom qab kev teeb tsa, tig qhov hluav taws xob thiab sim:
(1) Horn ua haujlwm
(2) Cruise/audio nyees khawm teb
(3) SRS lub teeb ceeb toom kaw tom qab tus kheej - kuaj xyuas
4.Critical Safety Kauj Ruam: Tshem tawm cov roj teeb tsis zoo thiab tos tsawg kawg 10 feeb ua ntej tshem lub kauj tsheb kom tsis txhob muaj kev sib tsoo airbag.
